Electrical Insulating Rubber Matting IEC/BS EN 61111:2009

Vardhman Insulating Matting (Di-Electric Carpets) made of Rubber Compound suitable for providing the Electrical safety to the workmen working around the possible areas of Electrical shock and act as a safeguard equipment from electrical shock due to leakage of current, shot circuit or any other.

Electrical Rubber Matting manufactured by Vardhman conforms to IEC 61111 and comes with a double triangle logo. The special high quality Rubber Compound ensures the complete shock protection against electrical shocks due to electrical earth faults.

Our Mats are fully compliant With IEC 61111 (International Electro Technical Commission) and are regularly tested by third like TUV, Lloyds and many others. The mats offered by us are ROHS and PAH Compliant.

We at Vardhman, adopt the most advance technology to manufacture Insulating Mats. The state of the art line (German Technology) makes our quality and finish unmatchable in the industry.

All the testing and inspection facilities are established within the factory Which ensures every square inches of mat are fully tested to the specifications.

Application

The Mat can be used in Indoor and outdoor locations and are mostly used in front and rear side side of electrical panels, switchgears, transformers and other high voltage workplaces to provide the high safety environment for the workforce.

This mat can also be used as portable protection for site engineers working on live equipment.

Features and Advantages

  • Fully tested to specification IEC 61111.
  • Provides safety for operators against electrical shock.
  • High Electrical Resistance Up to 50 KV/50000 volts.
  • Suitable for both AC and DC Applications.
  • Health and safety regulation Halogen Free flame retardant material.
  • Highly Flexible mats with self-gripping design on floor.
  • Anti-Fatigue type. Comfortable while standing for long period.
  • Anti-Slip Finish. Tested to slip resist test.
  • Resistant to acid, oil and Low temperature test.
  • Ozone, UV and weather resistant.
  • Permanent Marking-Durable and un-erasable done while curing of mats.
  • Fully Traceable supply.
  • Low Maintainance.
  • No Recycled Rubber.
Class Standard Thickness Max. Use Voltage Proof Voltage Withstand Voltage Color Code
0 3 mm 1000 Volts 5000 Volts 10000 Volts Red
1 3 mm 7500 Volts 10000 Volts 20000 Volts White
2 3/6 mm 17000 Volts 20000 Volts 30000 Volts Yellow
3 4/6 mm 26500 Volts 30000 Volts 40000 Volts Green
4 4/6 mm 36000 Volts 40000 Volts 50000 Volts Orange

Note: Other thickness are also available on request. Maximum thickness offered in any class is 14mm.

Dimensions

Width 0.9mtr, 1.0mtr, 1.2mtr
Length 2mtr, 5mtr, 10mtr, 20mtr, or as per requirement
Thickness As Per Specified Class
Colors Black, Blue, Grey
Surface/Design Anti-Skid Texture Finish

Note: Other colors also available on request.

Other Properties

S.No. Technical Specification All Classes
1 Composition and Surface Rubber elastomer*, Anti Skid Finish. Macromolecular material which returns rapidly to its final dimension by a weak stress and release of the stress.
2 Workmanship Mats shall be free from Harmful physical irregularities.
3 Mechanical Puncture Resistance Min. 70N
4 Slip Resistance Test @ force of 70N Maximum 15mm
5 Ageing Test at 70 deg cl./168hrs. Puncture Resistance shall be min. 80% of original value.
6 Flame Retardant Test Flame shall not reach any point on a 50mm circle.
7 Thermal Test (Low Temp. Test) No Crack@100N.
No-Breakdown on specified voltage.
8 Acid Test; H2SO4 For 8hrs. Minimum Retention in Mech. Puncture Test initial value. Min. 75% Retention & No Breakdown on specified Voltage.
9 Oil Test; oil for 2hrs.
Minimum Retention in Mech. Puncture test initial value.
Min. 75% Retention & No Breakdown on specified Voltage.

Confirm Marking

The marking on the top side (always visible) of the safety mat will consist of following details:
The complete marking shall be marked at least once on every meter of mat. The marking shall be colour coded as per IEC 61111:2009 guidelines.
Class '0' - RED, Class '1' - WHITE, Class '2' - YELLOW, Class '3' - GREEN, Class '4' - ORANGE
